Honeywell humidifier solenoid valve assembly with water tube

Honeywell Humidifier Solenoid Valve Assembly with Water Tube — 32001639-002/U

SKU: 32001639-002/U

$227.20
Stock: 3 units

Description

  • The Honeywell Humidifier Solenoid Valve Assembly with Water Tube is a premium, factory-certified OEM replacement fluid control kit designed to regulate automatic water distribution within high-performance forced-air furnace humidification networks.
  • Precision-machined with a heavy-duty structural brass body, this 24-volt AC solenoid control valve utilizes low power consumption while effortlessly handling intense internal line pressures up to 10 Bar.
  • The specialized design includes a factory-installed stainless steel sediment filter screen and an integrated metering orifice that actively stops fine sand, scale, and rust pieces from blocking water injection pathways.
  • Mechanical contractors and facility engineers can deploy the 32001639-002/U turnkey kit—complete with its premium 22-1/2 inch rubber feed hose and distribution nozzle—to instantly solve system short-cycling, completely stop pad dry-outs, and ensure smooth relative humidity output during active heating cycles.

Specifications

Manufacturer / Brand

Honeywell Home (Resideo Technologies, Inc.)

Product Line / Series

OEM Humidification Replacement Parts

Manufacturer Part Number / SKU

32001639-002/U

UPC

085267252277

ASIN

B000I0PJ8K

Operating Voltage

24 VAC, 60 Hz

Power Consumption

2.3 Watts low power draw

Maximum Fluid Pressure

Rated up to 10 Bar (145 PSI)

Inlet/Outlet Port Interface

1/4" Barb and custom multi-angle compression hardware fittings

Item Packaging Weight

272 grams (0.60 lbs)

Physical Module Dimensions

89.0 mm x 132.0 mm x 89.0 mm (3.50" x 5.20" x 3.50")
