The YELLOW JACKET® RecoverXLT® has all the features you need for fast and effective refrigerant recovery. The single control valve makes it easy to operate. The dual-gauge design allows for monitoring of the system and tank pressures simultaneously and the integrated low-pressure switch automatically powers down the machine when the system reaches 15” of vacuum.
The 1.25 hp, twin cylinder, oil-less compressor backed by a 3-year warranty provides fast recovery of Class III, IV and V refrigerants including R-410A. Gravity-drain condenser and high efficiency fan keep the recovery cylinder cooler, even in hot weather.
Integrated purge circuit clears residual refrigerant from the machine, preventing cross-contamination when changing from one refrigerant to another.
The RecoverXLT® helps you get the job done right
- Capabilities: Vapor, liquid, push/pull
Refrigerants: All Class III, IV, and V, including R-410a refrigerants
Compressor: 1.25 hp, twin cylinder, oil-less
Power Source: 100-240VAC, 50/60Hz
Amps: 12.0A
High-Pressure Shut-Off: 517 psi/35 bar – auto reset
Operating Temperature: 40° to 122°F (0° to 50°C)
Weight: 26.7 lbs (12.1 kg)
Dimensions: 19.3”L x 12.5”W x 12.4”H (490mm x 317mm x 315mm)See Product Spec Sheet under documents for UL Certified Rates for ARI 740-2016 for R12, R-134a, R-22, R-410, R-500 and R-502.
The RecoverXLT™ is approved for use with other refrigerants which have not been certified for a particular recovery rate including, but not limited to: R1234YF, R-22, R-32, R134A, R-401A, R401B, R-402A, R-402B, R-404A, R-406A, R-407A, R-407B, R-407C, R-407D, R-408A, R-409A, R-410A, R-411A and R-411B, R-454B, R-500, R502.
-
- A2L Compatible
- Single valve control for easy changeover from liquid to vapor to purge
- Robust compressor design for fast recovery of liquid and vapor refrigerant
- Advanced 1.25 hp, twin cylinder, oil-less compressor with precision valves
- Recovers refrigerant and shuts off when unit reaches 10″ of vacuum
- Status indicator LED provides notification of machine faults and completed recovery
- Quiet running with components nested to reduce vibration and noise – oil-less compressor is inherently quiet
- Controls and gauges inset for protection and angled for easy access and viewing
- Senses back pressure from tank and shuts off automatically at 517 psi for safety
- Reusable mesh particulate filter inserts into suction port for protection – simple cleaning eliminates replacement due to clogging
- ”On-the-fly” purge with simple turn of a knob to remove residual refrigerant and help prevent cross-contamination
- High efficiency fan keeps air moving across condenser for cool running even in hot weather
- High strength HDPE case for lightweight and rugged use –rounded corners help protect from nicks and scrapes
