InOvate Dryerbox Model 425 Recessed Metal Dryer Vent Box for 2×6 Walls Upward Venting — DB-425

InOvate Dryerbox Model 425 Recessed Metal Dryer Vent Box for 2×6 Walls Upward Venting — DB-425

SKU: DB-425

$117.00
Stock: 5 units

Description

  • The Dryerbox Model 425 Recessed Metal Dryer Vent Box is an industrial-grade, deep-drawn architectural safety component engineered for new construction installations within 2" x 6" stud framing cavities.
  • Fabricated from heavy-duty 22-gauge aluminized steel, this code-compliant receptacle forms a seamless recessed pocket that houses flexible transition hoses without crushing, effectively reducing dangerous lint-trapping kinks and enhancing appliance drying cycle efficiency.
  • Featuring a built-in 4-1/8" top exhaust port and a UL Classified 1-hour fire rating, it eliminates the need for restrictive elbows while establishing an excellent flame barrier within wood or steel framing bays.
  • Professional HVAC contractors, home builders, and facility management crews can deploy the DB-425 to allow clothes dryers to rest completely flush against finished drywall, maximizing usable square footage in cramped residential laundry suites and mechanical closets.

Specifications

Manufacturer / Brand

InOvate (InOvate Technologies, Inc.)

Product Line / Series

The Dryerbox® Series

Manufacturer Part Number / SKU

DB-425

UPC

899470002011

ASIN

B008J4WY58

Wall Framing Profile

Designed for 2" x 6" timber or steel stud bays (Can fit 2" x 4" bays if a minimum 1" furring strip is attached)

Exhaust Port Configuration

4-1/8" top port with a very slight oval shape to receive standard 4" rigid aluminum ducting

Overall Frame Exterior Dimensions

21" H x 12-1/2" W x 5-1/8" D (533 mm x 318 mm x 130 mm)

Internal Box Receptacle Dimensions

18-1/4" H x 9-1/2" W x 4-1/4" D

Item Unit Net Weight

1878 grams (4.14 lbs)
