Z flex z vent 2sveewcf0490 4 inch stainless steel 90 degree single wall vent elbow

Z-Flex Z-Vent 2SVEEWCF0490 4-Inch Stainless Steel 90-Degree Single-Wall Vent Elbow

SKU: 2SVEEWCF0490

$271.99
Stock: 10 units

Description

  • The genuine Z-Flex Z-Vent 2SVEEWCF0490 4-Inch Stainless Steel 90-Degree Single-Wall Elbow is a commercial-grade special gas vent fitting engineered to execute sharp directional turns and piping offsets inside high-efficiency exhaust configurations.
  • Expertly fabricated from premium AL29-4C super ferritic stainless steel with fusion-welded seams, this rigid 90° elbow offers ultimate structural resistance against the highly corrosive, acidic condensation generated by modern Category II, III, and IV power-vented appliances.
  • Featuring Z-Flex's patented built-in fail-safe rubber gasket and locking band system, it allows technicians to establish an immediate, gas-tight seal without messy high-temperature silicone sealants, providing an ultra-reliable drop-in solution rated for flue gases up to 550°F on tankless water heaters, high-efficiency furnaces, and commercial boilers.

Specifications

Manufacturer / Brand

Z-Flex

Manufacturer Part Number / SKU

2SVEEWCF0490

UPC

190302213719

ASIN

B003QSJIG0

Product Line / Series

Z-Vent® Series (SVE IV Single-Wall Special Gas Vent)

Vent Fitting Type:

90° Rigid Direction Change / Offset Pipe Elbow

Nominal Vent Pipe Diameter

4 Inches

Wall Configuration Type

Single-Wall Construction

Certifications & Compliance Standards

Fully UL 1738 Listed for the United States and cUL approved for Canada.
