Little Giant VCMA-20ULST Automatic Condensate Removal Pump with Safety Switch and 20-Foot Tubing — 554435

SKU: 554435

$140.00
Stock: 2 units

Description

  • The Little Giant VCMA-20ULST Automatic Condensate Removal Pump is a commercial-grade wastewater management system engineered to automatically collect and discharge corrosive gravity-drained runoff from high-efficiency furnaces, central air conditioning units, and heavy-duty dehumidifiers.
  • Powered by a robust 1/30 HP fan-cooled motor, this high-performance pump safely handles up to 80 GPH while effortlessly pushing fluid through a maximum 20-foot vertical dynamic head lift using the included premium clear vinyl tubing bundle.
  • The half-gallon structural ABS collection tank incorporates three distinct drop-in inlet openings alongside a pre-wired high-sensitivity safety overflow switch that can instantly kill connected HVAC equipment or broadcast field alarm codes to prevent destructive building flood disasters.
  • Perfect for plumbing technicians, building managers, and sheet metal mechanics, the 554435 kit features an integrated brass check valve to eliminate fluid backflow and safeguard continuous system negative static pressure loops.

Specifications

Manufacturer / Brand

Little Giant (Franklin Electric Co., Inc.)

Product Line / Series

VCMA Series Condensate Elimination Pumps

Manufacturer Part Number / SKU

554435

UPC

010121144355

ASIN

B000SM342A

Supply Voltage Rating

115 VAC, 60 Hz

Output Power / Horsepower

1/30 HP (0.033 HP)

Flow Capacity Performance

80 Gallons Per Hour (GPH) at zero head lift (303 Litres per hour)

Maximum Dynamic Head Lift

20 Feet (6.1 meters / 8.6 PSI maximum shut-off threshold)

Electrical Current Draw

1.5 Amps / 60 Watts high-torque motor configuration

Tank Holding Capacity

1/2 Gallon (1.9 Litres) ABS collection tank reservoir

Item Unit Net Weight

2,450 grams (5.40 lbs)

Physical Assembly Footprint

177.8 mm H x 279.4 mm W x 127.0 mm D (7.00" Height x 11.00" Width x 5.00" Depth)
