Johnson Controls Dual Pressure Control High/Low HVAC Switch — P70LB-1C

SKU: P70LB-1C

$650.00
Stock: 4 units

Description

  • The Johnson Controls P70LB-1C Dual Pressure Control High/Low HVAC Switch is an industrial-grade, commercial-grade equipment component engineered specifically to ensure continuous high-and-low-side compressor protection across demanding commercial refrigeration and chiller infrastructure.
  • Fabricated from premium galvanized steel housing components and heavy-duty copper-alloy bellows, this high-performance component handles extreme system variables across a 100-500 PSIG high-side threshold with dual automated reset loops while permanently resisting contact arcing and diagnostic drift.
  • The innovative adjustable high/low differential mechanism significantly improves system control precision to smoothly handle sudden load shifts and refrigerant spikes without causing short-cycling or catastrophic system failures.
  • Ideal for licensed HVAC/R technicians, mechanical contractors, and facility maintenance supervisors, this durable dual-pressure switch features universal flare terminals and an easy-access parameter scale to rapidly execute clean, direct field installations, maximize overall energy efficiency, and permanently eliminate expensive equipment failure callbacks.

Specifications

Manufacturer / Brand

Johnson Controls Inc. (PENN Refrigeration Components Division)

Product Line / Series

P70 Series Dual Pressure Controls

Manufacturer Part Number / Master SKU

P70LB-1C

UPC

785028292957

ASIN

B00CPSRABW

Low Pressure Cut-In Range

20 to 100 PSIG system window

Low Pressure Adjustable Differential

7 to 50 PSIG variable range

High Pressure Cut-Out Range

100 to 500 PSIG system window

High Pressure Adjustable Differential

65 to 95 PSIG variable range

Pneumatic Connection Interface

Dual 1/4" SAE flare pressure nut ports

Electrical Contact Rating

120 VAC / 240 VAC pilot duty circuits

Ambient Thermal Tolerance

-30°F to 140°F (-34°C to 60°C)

Item Unit Net Weight

1496.85 grams (3.30 lbs)
