MARS 780 61757 Professional-Grade Definite Purpose Contactor, 2-Pole, 40A FLA, 240V Coil

SKU: 61757

$100.00
Stock: 1 unit

Description

  • The MARS 780 61757 2-Pole 40A Definite Purpose Contactor is a commercial-grade electrical control module engineered to deliver ultra-reliable high-current switching across today's most demanding HVAC, refrigeration, and electric heating loops.
  • Operating on a 208-230V coil configuration with premium silver-cadmium oxide contacts, this high-performance dual-pole switch features an enclosed thermoplastic body layout that protects the electrical junctions from moisture and dirt while significantly dampening low-frequency coil vibrations.
  • Built with high-conductivity copper and brass internals to minimize heat buildup, the 61757 integrates heavy-duty box lug terminals and quad quick-connect spade taps with an oversized arch window housing frame, streamlining field wiring changes for central A/C compressors, duct heaters, and light industrial motor systems.

Specifications

Manufacturer / Brand

MARS (Motors & Armatures, Inc.)

Manufacturer Part Number / SKU

61757

UPC

685744617570

ASIN

B00LO33Q3K

Product Line / Series

MARS 780 Professional Grade Series

Number of Poles

2-Pole (Double Pole, Single-Phase Setup)

Full Load Amperage (FLA) Inductive

40 Amps

Resistive Amperage (RES) Rating

50 Amps

Control Coil Actuation Voltage

208-240 VAC

Coil Frequency Operational Range

50 / 60 Hz

Physical Housing Footprint

4.20" Length x 2.50" Width x 2.90" Height
